WK-1800
Technical Specifications

-
Aerocraft
Symmetrical motor wheelbase 1900mm Body size Expand: 2070 × one thousand and eight hundred × 910mm (boom unfolded, blade folded); Fold: 1100 × nine hundred and fifty × 910mm Maximum takeoff weight 56.1kg Paddle Blade diameter × Pitch: 34 × 11.2inch; Single weight: 190g electric machinery KV value: 100rpm/V Stator size: 96 × 16mm Electric regulation Continuous current: 120A (good heat dissipation condition); Lithium battery: 6~12S; Battery Voltage: 45.6V; Capacity: 66000 mAh; Energy: 3009.6 Wh; Type: LiHV 12S; Discharge current: 25C Maximum lifting speed 5m/s Maximum descent speed 3m/s Maximum horizontal flight speed GPS mode: 5~10m/s (windless environment) adjustable; Cruise mode: 10m/s (windless environment); Attitude mode: 15m/s (windless environment) Maximum pitch angle 35° Maximum rotation angular velocity Pitch axis: 120 °/s, heading axis: 50 °/s Maximum tolerable wind speed 12m/s Maximum flight altitude 5000m Hover accuracy (GPS) Vertical: ± 0.5m, horizontal: ± 0.5m (when GPS positioning works normally) Maximum endurance 50 minutes -
PTZ
size one hundred and thirty-six × ninety-eight × 139mm weight 452g input voltage 12V Stabilization system 3-axis (pitch, roll, level) Angle control accuracy Static: ± 0.008 °; Dynamic: ± 0.02 °; Anti shake: ± 0.008 ° Controllable rotation range Pitch: - 110 ° to+60 °; Horizontal: ± 150 °; Roll: ± 10 ° Maximum control speed Pitch: 30 °/s; Horizontal: 30 °/s -
Reconnaissance camera
Lens Pixel 12 million Focus time 2 seconds sensor 1/2.3 SONY IMX117 CMOS ISO Scope Video: 100 ~ 3200; Photo: 100~1600 Video recording resolution 4K 30fps Photographic resolution three thousand eight hundred and forty × two thousand one hundred and sixty focal length 6.7-134.5mm Zoom magnification 30x optical zoom Multiplying speed About 2.0 seconds Horizontal perspective 59.8 °~ 3.0 ° (wide-angle - telescopic) Close-up distance 5000mm (wide angle - far view) Video storage bitstream 64Mbps maximum Compression standard H.264 / H.265 Support file storage format File system: FAT32; Picture format: JPG; Video format: MP4 Supported memory card types Micro SD card, supporting up to 128G, with transmission speed of Class10 or above or reaching UHS-1 rating -
Dry powder fire extinguisher
texture of material HP295 Filling Pressure 1.2MPa Total weight 19kg Installation method Quick hanging type Net content of dry powder 12kg Open mode Electric control quick opening -
Dusting pipe
texture of material carbon fibre length Expand 4.33m (the shortest can be reduced to 1.61m) -
Specification of water hose
diameter 25mm length 100m Maximum pressure 2.0MPa -
Sprinkler pipe
texture of material carbon fibre length Expand 3.04m (the shortest can be reduced to 1.61m)
